Technical Specifications
Performance
- Nominal Voltage
- 230V
- Operational Voltage Range
- 216–244V
- Grid Connection
- Single Phase
- Rated Frequency
- 50Hz
- Rated Current
- 63A
- Main Switch
- MCB 63A Type C
- Overvoltage Category
- Category III
- Bus Bar Rating
- 75A
- Maximum Input Short Circuit Current
- 3kA
- Rated Diversity Factor
- 0.5
- Earthing Terminals
- 6 (3 left, 3 right)
- Neutral Terminals
- 6 (3 left, 3 right)
Input supply
- Meter Function
- Import & Export 1% Accuracy Supply Control Switch
Energy meter
- Controllable Circuits
- 20 Circuits (40A max per Circuit)
- Configurable MCB overcurrent ratings
- 2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A
- Configurable MCB types
- B, C, D (for D, up to 20A only)
- Configurable RCD trip ratings
- 10mA, 30mA (rated currents dependent on MCB)
- RCD types
- A, B
- Subcircuit Features
- Load Control Relay, Power Measurement
- Connectivity
- Ethernet, Wi-Fi 5 (2.4/5GHz), Bluetooth
Controllable subcircuits (RCD/AFDD/MCB)
